Type:

• Scale: 1/10th
• Brushed/Brushless: BL
• Sensored/Sensorless: SD
• Waterproof: Waterproof

Specifications:

• Cont./Peak Current: 80A/520A
• Input Voltage: 2-3S LiPo
• BEC Output: 6/7.4V, 5A

Wires & Connectors:

• Input Wires: Red-12AWG-159=0mm*1 Black-12AWG-150mm*1
• Output Wires:
• Input Connectors: XT60
• Output Connectors: 4.0mm Gold (Female)

Fan:

• Size: 25x25x10mm
• Output Wires: 5-7.4V
• Input Connectors: Powered by BEC

Esc Programming Via:

• SET Button on ESC: No
• LED Program Box: Supported
• LCD Program Box: Supported (G2)
• OTA Programmer: Supported
• Programming Port: Separate

Firmware:

• Firmware Upgrade: Supported

Size & Weight:

• Size: 53mm*39.5mm*37.2mm
• Weight: 120g(w/Wires)

Applications:

• SL BL Motors / SD BL Motors Vehicles: 1/10th On-Road / Off-Road Short Course / Truck (Light-Duty)
• KV Rating / T Count: With 2S LiPo: KV<6000, With 3S LiPo: KV<4200 3652 Size Motor
