O.S. MAX 37SZ-H Ring w/o Drive Washer

O.S. MAX 37SZ-H Ring w/o Drive Washer

In stock

Click to enlarge

O.S. MAX 37SZ-H Ring w/o Drive Washer

Stock code l-os14000
  Good stocks
Available for same day despatch Mon–Fri if ordered before 2pm, when possible
£220.00Each


Following on from the concept developed in the 70SZ-H, the latest 37SZ-H brings a new level of performance to '30-class' helicopters.

Just about everything has been changed compared to the 32SX-H in the pursuit of power and control. That super-rigid crankcase contains a highly developed, ringed piston/liner set and optimised crankshaft for the right combination of power and smoothness. The new carburettor has been purpose designed for precision control and is capable of being operated by push-pull linkages if required.

This is the perfect engine to compliment your new Hirobo Sceadu Evo and move your flying on to a new level

  • The crankshaft has been re-engineered to reduce vibration, resulting in smooth power across the entire rpm range.

  • A larger rear bearing boosts power even more.

  • Features the same mounting pattern and muffler dimensions as the 32SX-H, for easy installation in most 30-size helis

Displacement:        0.37 cu in (6.07 cc)
Bore:                     0.806 in (20.5 mm)
Stroke:                  0.725 in (18.4 mm)
Practical rpm:        2,000-21,000
Output:                 1.4 hp @ 18,000 rpm
Weight:                 10.3 oz (293 g)
Includes:               20M carburetor, #8 glow plug
Requires:               muffler, drive hub
