Main Control IC
Using ARM M3 processor, provides strong resolution capability.

High Sensitivity
Adopting 2.4GHz direct sequence spread spectrum (DSSS) and multiple frequency-hopping spread spectrum (FHSS) technology, the receiver has high sensitivity and strong anti-interference capability.

Diversity Antenna
By using diversity antenna, can automatically switch the signals to ensure the stability of the received signal.

Unique ID Code
Each transmitter has an individually assigned, unique ID code. Once the binding is made, the ID code is stored in the receiver and no further binding is necessary after restarting the receiver.

Fail Safe
When the aircraft flies out of range, the receiver cannot receive a valid RF signal from the transmitter, and will move the servos to predefined position.

Output Signals
Support PPM and PWM signals.

Spec Check:

• Dimension: 27.5x42x16mm
• Weight: 11.8g
• Frequency: 2.4GHz
• Communication Distance: >1.6Km
• Power Supply: 3.6V~16V
• Output Signal: PWM or PPM
